SuMe: Meshtastic Base Node
Jump to navigation
Jump to search
Sudo Room's Meshtastic base node. We do Meshtastic and other p2p decentralized comms at Radio Wednesdays!
| Short Name | SuMe |
| Long Name | Sudo Mesh |
| Device Role | CLIENT_BASE |
| Node Number | 1802472876 |
| User ID | !6b6f8dac |
| location | temporarily by the giant dish over the sudo mesh cage, eventually on the roof!! JH and User:Jerkey |
| case | 3d printed by User:Isilva, file found on Printables |
| hardware | procured and assembled by User:Isilva |
| power source | long USB cord that plugs into junk.local |
| web interface | http://junk.local:5000 and maintained by User:Judytuna |
Web interface to view and send messages
Use this webpage to view incoming messages and send messages to nodes or the MediumFast channel. Every time a message comes in as a DM, the computer reads it aloud to Sudo Room.
Address: http://100.64.64.10:5000/
It is a Python/Flask program running on junk.local which is in the server rack. SuMe is connected to junk via usb cord.
code at https://github.com/sudoroom/meshtastic-web (courtesy of User:Judytuna using Claude.ai lol)
Hardware
| Brand | RAK |
| Model Name | RAKwireless WisBlock |
| Base Board | RAK19007 |
| LoRa Module | RAK4631 (Nordic nRF52840) |
| CPU Model | Core i7 |
| Connectivity | USB, BLE |
